Description
Our 45,000-Liter Diesel Fuel Tanker is engineered for efficient and secure fuel transportation. Constructed with durable materials and equipped with advanced safety features, this tanker is designed to handle bulk fuel delivery while ensuring leak prevention and convenient refueling operations.
This diesel fuel trailer comes with integrated systems that enhance safety, durability, and performance in demanding fuel transport operations. It is ideal for oil companies, logistics fleets, and industries requiring bulk fuel supply.
Product Specifications:
| Tank Size (L × W × H) | 9150 × 2480 × 2000 mm |
| Wheelbase | 4450 + 1310 + 1310 mm |
| Tank Body | Cylinder 5.5mm, Wave-proof board 5.5mm, Head 6.0mm |
| Axle | 3 × 13T 220 axles |
| Tires | 11.00R20 12PR; 12R22.5 12PR |
| Steel Ring | 12 pcs 9.0 × 22.5 steel ring |
| Landing Legs | Aluminum alloy 8T single-acting legs |
| Plate Spring | 4 pcs pressed 2, 22mm thick |
| Max Medium Density | 925 kg/m³ |
| ABS System | Factory-equipped 4S/2M |
| Traction Pin | 90# traction pin (assembled) |
| Manhole Cover | 2 stainless steel nine-claw covers with aluminum seat rings and anti-theft box |
| Mudguard | Aluminum alloy round arc wing |
| Insulation | Aluminum leather insulation with bandages and two heating tanks |
| Toolbox | 1 unit |
| Tire Carrier Frame | 1 unit |
| Air Chamber | 4 pairs and 2 singles |
| Gas Storage Cylinder | 2 × 50L sets |
Key Features:
- Durable Construction: Made from high-strength steel, ensuring resistance to corrosion and wear for long service life.
- Efficient Pump System: Optional high-performance pump system available for fast, efficient fuel transfer operations.
- Advanced Leak-Proof Technology: Integrated systems prevent spillage and fuel loss, guaranteeing safe delivery.
- Enhanced Safety Features: Includes fire extinguishers, emergency shut-off valves, and locking mechanisms for secure operation.
- Versatile Capacity Options: Available in various sizes to suit different industries and fuel delivery needs.
- Easy Maintenance: Simple structural design allows for quick cleaning and servicing with minimal downtime.
Additional Design Details:
- Double Fire Extinguishers for emergency safety
- Integrated Piping System for stable fuel transfer
- Integrated Side Tool Box for accessory storage
- Quick-Opening Nine-Claw Manhole Covers
- Built-in Hose Box & Reinforced Fenders
- Rear Anti-Impact Protection Structure
Packing & Shipping:
We have established global trade relationships, successfully exporting fuel trailers to Southeast Asia, the Middle East, Africa, and South America.
- Container Transport: Ideal for compact and mid-size fuel trailers.
- Roll-on/Roll-off (Ro-Ro): Trailers are driven onto vessels for fast and safe handling.
- Bulk Cargo Shipping: Suitable for large volume shipments with cost-efficiency.
Each shipping method is selected for optimal safety and cost-effectiveness. Trailers are securely packed and protected for international delivery.
