Description
This Petrol Trailer and Petrol Tanker Trailer, available in Tanzania, is designed for efficient liquid cargo transportation. Built with an advanced steel body structure, it offers a leak-proof design and 100% sealed transport, minimizing the risk of spills. With a maximum capacity of 116m³, it ensures stable handling and high performance.
The 70,000L Petrol Trailer is made from high-strength steel, stainless steel, or aluminum alloy to suit different liquid transport needs. Capacity options range from several thousand liters to tens of thousands, based on customer requirements and regional regulations.
Key safety features include:
- Safety valves, pressure gauges & leak detectors
- Emergency cut-off & fire protection systems
- Anti-corrosion coating for durability
Product Specifications:
| Insulated Outer Tank Size (L × W × H) | 10,860 × 2,540 × 2,250 mm |
| Wheelbase | 5,540 + 1,310 + 1,310 mm |
| Tank Body | 5.5mm wave-proof board, 5.5mm body, 6.0mm head |
| Axles | 3 × 13T 220 axles |
| Tires | 12 × 12R22.5 tubeless tires (factory-equipped) |
| Steel Rings | 12 pcs, 9.0 × 22.5 |
| Landing Legs | Aluminum alloy 8T single-acting legs |
| Plate Springs | 4 pcs, pressed, 22mm thick |
| Air Chamber | 4 pairs and 2 singles |
| Gas Storage Cylinder | 2 sets of 50L |
| ABS System | Factory-equipped 4S/2M |
| Traction Pin | 90# traction pin (assembled) |
| Manhole Cover | 2 stainless steel nine-claw covers with aluminum seat ring and anti-theft box |
| Mudguard | Aluminum alloy round arc wing |
| Insulation | Aluminum leather insulation with two heating tanks |
| Toolbox | 1 unit |
| Tire Carrier Frame | 1 unit |
| Max Medium Density | 800 kg/m³ |
Key Features of the Tanker Semi-Trailer:
- High-Strength Construction: Built with steel thicknesses of 5.5–6.0mm, ensuring superior durability and impact resistance.
- Advanced Braking System: Equipped with 4S/2M ABS for enhanced control and safety under heavy load.
- Secure Coupling: 90# traction pin ensures a firm and stable connection between trailer and tractor head.
- User-Friendly Design: Features include a practical toolbox and an easy-to-maintain exterior.
- Comprehensive Safety Equipment: Leak detectors, pressure gauges, safety valves, fire protection, and emergency cut-off systems for maximum security.
- Efficient Operation: Streamlined for easy loading/unloading and cleaning to optimize time and performance.
- Custom-Built Options: Can be tailored to local transport needs, cargo types, and safety regulations.
Industries & Applications:
- Petrochemical Sector: Crude oil, gasoline, diesel, and lubricants for long-haul routes.
- Food Processing & Transport: Cooking oil, alcohol, and juice transport with hygienic sealing.
- Chemical Industry: Safe handling of corrosive or hazardous chemicals with full regulatory compliance.
- Agriculture & Agro-Processing: Fertilizers, agrochemicals, and processed liquids for farming operations.
- Environmental & Cleaning Services: Liquid waste and sewage transport, with options for vacuum or pump systems.
Secure Packaging & Global Shipping:
We have established trade partnerships worldwide, successfully delivering tanker semi-trailers to Southeast Asia, the Middle East, Africa, and South America.
- Container Shipping: Used for compact trailers and standard routes.
- Ro-Ro (Roll-on/Roll-off): Trailers are driven onto vessels for fast, secure loading and unloading.
- Bulk Transport: Ideal for high-volume orders, optimizing cost and freight efficiency.
Each unit is safely packed, secured, and inspected before shipment to ensure damage-free delivery.
