Description
This chemical tanker trailer is engineered for durability and reliability in handling hazardous substances. The tank is treated with high-performance anti-corrosion coatings inside and out, preventing chemical damage and ensuring leak-proof transport.
For enhanced safety and stability, the trailer features anti-wave plates to reduce liquid movement, an explosion-proof manhole cover, and emergency shut-off valves. Partition plates allow independent loading and unloading, making it ideal for transporting multiple chemicals at once.
Product Specifications:
| Overall Dimensions (L × W × H) | 11050mm / 10930mm × 2550mm × 3600mm |
| Max Medium Density | 1280 kg/m³ |
| Material Options | Carbon Steel / Stainless Steel |
| Tank Capacity | 27m³ |
| Axle Configuration | 3 axles |
| Tire Options | 11.00R20 12PR / 12R22.5 12PR |
| Suspension Type | Mechanical Suspension / Air Suspension |
| Kingpin Sizes | #50 (2″) / #90 (3.5″) – JOST or compatible brands |
| Landing Gear | 28-ton two-speed, VEHICLE MASTER / JOST / Other |
Key Features of Chemical Tanker Trailers:
- Reinforced Steel Ring: Strengthens the tank structure for improved resistance against pressure and deformation.
- Bottom Valve: Secure sealing system that prevents leaks during transit and unloading.
- Static Conductive Mopping Strip: Minimizes static buildup inside the tank to reduce fire or explosion risk.
- Axle System: Provides superior load distribution and stability under heavy weight.
- Spare Wheel Carrier: Conveniently located for quick access and roadside assistance.
- Discharge Port: Engineered for precise and safe unloading of chemical liquids, improving operational safety.
Packaging and Shipping:
We have successfully supplied chemical tanker trailers to Southeast Asia, the Middle East, Africa, and South America. Our logistics team ensures timely, safe, and cost-effective delivery tailored to your order size and destination. Shipping methods include:
- Container Transport: Compact and secure for medium to smaller orders.
- Ro-Ro (Roll-On/Roll-Off): Ideal for fully assembled tankers ready for use.
- Bulk Shipment: Economical for fleet-scale or high-volume trailer deliveries.
Every trailer is thoroughly inspected and protected against corrosion and transport damage prior to shipment.
